Condenser Fan Motor 10w 220v 50-60Hz China. دينمو ثلاجه

This is a high-performance, single-phase shaded pole asynchronous motor, primarily designed for use in refrigeration and ventilation equipment, including refrigerators, freezers, and beverage coolers. It features a durable, cast aluminum housing for efficient heat dissipation and robust performance. ​Key Specifications: ​Input Power: 220V - 240V AC ​Frequency: 50/60 Hz ​Power Output/Input (P out/P in): 10/40W ​Current: 0.25 Amps ​Rated Speed: 1300 - 1500 RPM (Rotations Per Minute) ​Rotation: Counter-Clockwise (CCW) viewed from the shaft end (standard for many applications, though it's always best to confirm with the specific appliance). ​Insulation Class: Class B (Standard thermal endurance suitable for typical home and commercial refrigeration environments). ​Certifications: Includes CE marking, indicating compliance with European safety standards. ​Connections: Features a single 2-wire power cable (often black), without an earth (ground) wire, typical for shaded pole motors. It uses blade connector terminals or standard stripped leads for installation. ​Mounting: Designed for standard four-post mounting (visible in the image as protruding bolts) for secure installation into fan brackets or housing. ​Aesthetics: Housed in a clean, raw aluminum finish with a clearly visible specification sticker and a distinct black "C-N" logo in a stylized starburst pattern on the top and the text "COOLING MAP" at the bottom. ​Application: This versatile motor is an ideal replacement part for numerous refrigeration units. It is commonly used as a condenser fan motor (for cooling the condenser coils) or an evaporator fan motor (for circulating cold air inside the unit), ensuring efficient operation of the appliance. ​Note: Always ensure power is disconnected and proper safety procedures are followed during installation. Check compatibility with your specific appliance model and part number before purchasing. The rotation direction is critical for proper airflow.
